User benefits
- LED light illuminates the work site
Standard machines
View more
View less
Technical specifications
-
Nominal Battery Voltage12 V
-
Li-ion battery 12V max2 x 2,0Ah (24Wh)
-
Average Charging Time70 min
-
CXT Battery
-
Number of Batteries Supplied2
-
Battery protection
HP331DZ:
Li-ion battery 12V max:
-
CXT Battery:
Battery protection:
No load speed:
0 - 450 / 0 - 1700 min⁻¹
Impacts per Minute (IPM):
0 - 6750 / 0 - 25 500 min⁻¹
Max. fastening torque Hard/Soft:
30 / 14 Nm
Clutch torque setting:
18
Max. Drilling Diameter in Wood:
21 mm
Max. Drilling Diameter in Concrete:
8 mm
Max. Drilling Diameter in Steel:
10 mm
Drill Chuck Capacity:
0,8 - 10 mm
Sound Power Level (LWA):
92 dB(A)
Sound Pressure Level (LpA):
81 dB(A)
Noise Uncertainty (K Factor):
3 dB(A)
Vibration Level (3 axes):
≤ 2,5 m/s²
Vibration Level (3 axes), Impact Drilling:
8,0 m/s²
Vibration Uncertainty (K Factor):
1,5 m/s²
Tool weight with battery (EPTA):
1,1 - 1,3 kg
Product Dimensions (L x W x H)::
201 x 66 x 209 mm
TM30DZ:
Li-ion battery 12V max:
-
CXT Battery:
Battery protection:
Orbits per Minute:
6000 - 20000 min⁻¹
Oscillation Angle:
2 x 1,6 °
Pad size (triangle):
93 x 93 x 93 mm
Sound Pressure Level (LpA):
81 dB(A)
Noise Uncertainty (K Factor):
3 dB(A)
Vibration Level (3 axes):
1,5 - 10,5 m/s²
Vibration Level (3 axes), Cutting Chipboard:
5,5 m/s²
Vibration Level (3 axes), Sanding:
2,5 m/s²
Vibration Uncertainty (K Factor):
1,5 m/s²
Tool weight with battery (EPTA):
1,1 - 1,3 kg
Product Dimensions (L x W x H)::
296 x 65 x 98 mm
Nominal Battery Voltage:
12 V
Barcode
Symbols:
Työvalo
Compatible devices
