Technical specifications
-
Nominal Battery Voltage12 V max / 18 V
-
Li-ion battery 12V max1 x 2,0Ah (24Wh)
-
Li-ion battery 18V2 x 5,0Ah (90Wh)
-
Average Charging Time30 - 45 min
-
CXT Battery
-
Voltage LXT
-
Number of Batteries Supplied3
-
Battery protection
-
Product net weight6,6 kg
-
Product Dimensions (L x W x H):30 x 30 x 28 mm
DF032DZ:
Li-ion battery 12V max:
-
CXT Battery:
Brushless Motor:
Battery protection:
No load speed:
0 - 450 / 0 - 1500 min⁻¹
Max. fastening torque Hard/Soft:
35 / 21 Nm
Clutch torque setting:
20
Max. Drilling Diameter in Wood:
28 mm
Max. Drilling Diameter in Steel:
10 mm
Sound Pressure Level (LpA):
71 dB(A)
Noise Uncertainty (K Factor):
3 dB(A)
Vibration Level (3 axes):
≤ 2,5 m/s²
Vibration Uncertainty (K Factor):
1,5 m/s²
Tool weight with battery (EPTA):
0,9 - 1,0 kg
Product Dimensions (L x W x H)::
124 x 66 x 217 mm
DHP485Z:
Li-ion battery 18V:
-
Nominal Battery Voltage:
18 V
Voltage LXT:
Battery protection:
Brushless Motor:
No load speed:
0 - 500 / 1900 min⁻¹
Max. fastening torque Hard/Soft:
50 / 27 Nm
Clutch torque setting:
21
Impacts per Minute (IPM):
0 - 7500 / 28 500 min⁻¹
Max. Drilling Diameter in Wood:
38 mm
Max. Drilling Diameter in Masonry:
13 mm
Max. Drilling Diameter in Concrete:
13 mm
Max. Drilling Diameter in Steel:
13 mm
Driving Shank:
1/2"-20UNF "
Drill Chuck Capacity:
1,5 - 13 mm
Sound Power Level (LWA):
93 dB(A)
Sound Pressure Level (LpA):
82 dB(A)
Noise Uncertainty (K Factor):
3 dB(A)
Vibration Level (3 axes), Drilling:
≤ 2,5 m/s²
Vibration Level (3 axes), Impact Drilling:
8,0 m/s²
Vibration Uncertainty (K Factor):
1,5 m/s²
Tool weight with battery (EPTA):
1,5 - 1,8 kg
Product Dimensions (L x W x H)::
182 x 79 x 255 mm
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion):
Li-ion
Barcode
0088381888325
