Petrol Chain Saw
EA3202S40B32 cm³ • 24,4 m/s • 16"
Compact and handy chainsaw
A light and easy-to-use chainsaw for general use. Thanks to its modern 2-stroke engine, the chainsaw has low consumption and emission levels. The tool has a 400 mm (16") guide bar and a 1,35 kW engine that generates a chain speed of 24,4 m/s. Equipped with an easy start function.
- **General**
- **Technical info**
- **Related Products**
- **Dust Extraction**
- **Additional info**
- **Support**
Technical specifications
-
Engine Speed at Max. Power1,35 kW
-
Chain Speed at Max. Power18,9 m/s
-
No load speed12 800 min⁻¹
-
Bar Size400 (16") mm
-
Chain Pitch3/8 "
-
Chain Gauge0,043 "
-
Chain Gauge1,1 mm
-
Fuel Tank Capacity0,4 L
-
Chain Oil Tank0,28 L
-
Primer pump
-
Spring-Assisted Start System
-
Displacement32 cc
-
Sound Power Level (LWA)109,8 dB(A)
-
Sound Pressure Level (LpA)102,6 dB(A)
-
Noise Uncertainty (K Factor)2,5 dB(A)
-
Vibration Level (3 axes) at Front Handle4,8 m/s²
-
Vibration Level (3 axes) at Rear Handle4,8 m/s²
-
Vibration Uncertainty (K Factor)2,0 m/s²
-
Product Dimensions (L x W x H):405 x 250 x 273 mm
-
Max. Chain Speed (No Load)24,4 m/s
Barcode
0088381634878
Symbols:
Tärinän vaimennus
Automaattinen ketjuvoitelu
Ketjujarru
Polttoainepumppu
