Petrol Chain saw

EA3601F35B

35 cm³ • 18,9 m/s • 14"

Efficient, light and low-energy chain saw with tool-less tensioning

Lightweight and easy-to-use chainsaw for general use. Thanks to its stratified air scavenging engine, it has low consumption and emission levels. The tool has a 350 mm (14") guide bar and a 1,7 kW engine that generates a chain speed of 18,9 m/s. Equipped with an Easy start function and tool-less bar and chain adjustment.

Not in stock

**General**

**Technical info**

**Related Products**

**Dust Extraction**

**Additional info**

**Support**

Technical specifications

Engine Speed at Max. Power

1,7 kW

Chain Speed at Max. Power

18,9 m/s

No load speed

13 500 min⁻¹

Chain Pitch

3/8 "

Chain Gauge

1,3 mm

Number of Drive Links

Chain Blade

3/8" / -52 / 1,3mm

Fuel Tank Capacity

0,3 L

Chain Oil Tank

0,26 L

Primer pump

Spring-Assisted Start System

Displacement

35,2 cc

Sound Power Level (L_WA)

111 dB(A)

Sound Pressure Level (L_pA)

99 dB(A)

Noise Uncertainty (K Factor)

2,5 dB(A)

Vibration Level (3 axes) at Front Handle

3,3 m/s²

Vibration Level (3 axes) at Rear Handle

3,4 m/s²

Vibration Uncertainty (K Factor)

2,0 m/s²

Product Dimensions (L x W x H):

388 x 235 x 272 mm

Specific Power (Weight to Power Ratio)

1,7 kg / kW

Max. Chain Speed (No Load)

25,3 m/s

Barcode

0088381655736

Symbols:

Automaattinen ketjuvoitelu

Ketjujarru

Tärinän vaimennus

Elektroninen sytytys

Käynnistyksen kevennin

Polttoainepumppu
