Rotary Hammer
HR2600X9800 W • SDS-Plus • 26 mm • 2,4 J
Professional two-mode rotary hammer
Efficient rotary hammer compatible with SDS-Plus bits. Suitable for impact and unstressed drilling. Motor capacity of 800 W and speed can be adjusted between 0 and 1 200 min-1 from a switch. Impact energy of 2,4 J and optimal drilling range of 8 – 18 mm in concrete. Max. drilling capacity of 26 mm in concrete.
- **General**
- **Technical info**
- **Related Products**
- **Dust Extraction**
- **Additional info**
- **Support**
User benefits
- Rear handle with soft rubber grip, ergonomically designed for comfortable operation
- 2-mode operation for "Rotation Only" or "Hammering with Rotation"
- Variable speed trigger allows operator to adjust speed based on materials or application
- One-touch sliding chuck for easy bit installation and removal
- Recessed lock-on button for continuous use
- Double insulated
Standard accessories
View more
View less
Technical specifications
-
Maximum Output Power800 W
-
No load speed0 - 1200 min⁻¹
-
Impacts per Minute (IPM)0 - 4600 min⁻¹
-
Max. Drilling Diameter in Wood32 mm
-
Max. Drilling Diameter in Concrete26 mm
-
Max. Drilling Diameter in Steel13 mm
-
Optimum Drilling Diameter Range in Concrete8 - 18 mm
-
Impact Energy2,4 J
-
Power Supply Cord2,5 m
-
Plastic Carrying Case
-
Side Grip
-
Depth Gauge (2)
-
Sound Power Level (LWA)102 dB(A)
-
Sound Pressure Level (LpA)91 dB(A)
-
Noise Uncertainty (K Factor)3 dB(A)
-
Vibration Level (3 axes), Drilling≤ 2,5 m/s²
-
Vibration Level (3 axes), Impact Drilling15,5 m/s²
-
Vibration: Chiselling9,5 m/s²
-
Vibration Uncertainty (K Factor)1,5 m/s²
-
Weight Without Cable (EPTA-Procedure 01/2003)2,8 kg
-
Product Dimensions (L x W x H):361 x 77 x 209 mm
Barcode
0088381622561
Symbols:
Kaksoiseristys
Portaaton nopeudensäätö
Suunnanvaihto
SDS-Plus kiinnitys
Turvakytkin
Pölynpoisto
Laukku
