User benefits
- Linear ball bearing ensures smooth dipping of the milling cutter
- Locking button for quick adjustment
- Three-position preselected revolver control
- Rip fence with 0.1 mm adjustable accuracy
- MAKPAC 4 content: suspension rail, adapter for the guide rail and 12-piece cutting cartridge
Standard accessories
View more
View less
Technical specifications
-
Maximum Output Power1850 W
-
No load speed22 000 min⁻¹
-
Length of Stroke0 - 70 mm
-
Max. Collet Capacity12 mm
-
Base dimensions170 x 155 mm
-
Power Supply Cord4,0 m
-
Plastic Carrying Case
-
Wrench
-
Guide Rule
-
Sound Power Level (LWA)97 dB(A)
-
Sound Pressure Level (LpA)86 dB(A)
-
Noise Uncertainty (K Factor)3 dB(A)
-
Vibration Level (3 axes)4 m/s²
-
Vibration Uncertainty (K Factor)1,5 m/s²
-
Weight Without Cable (EPTA-Procedure 01/2003)6,0 kg
-
Product Dimensions (L x W x H):155 x 294 x 312 mm
Barcode
0088381642224
Symbols:
Kaksoiseristys
Pölynpoisto
Työvalo
Laukku
Optional accessories
