User benefits
- Ultra compact design at only 168 mm long.
- LED light illuminates the work site
- Battery protection system automatically shuts off power when the battery level is low
- Body model - delivered without battery and charger.
Standard machines
View more
View less
Technical specifications
-
Li-ion battery 12V max-
-
CXT Battery
-
Battery protection
-
No load speed0 - 2600 min⁻¹
-
max fastening torgue impact drill145 Nm
-
Tightening Capacity Standard BoltM8 - M16
-
Impacts per Minute (IPM)0 - 3200 min⁻¹
-
Drive Square1/2 "
-
Sound Power Level (LWA)104 dB(A)
-
Sound Pressure Level (LpA)93 dB(A)
-
Noise Uncertainty (K Factor)3 dB(A)
-
Vibration Level (3 axes), Fastening Bolt7,5 m/s²
-
Vibration Uncertainty (K Factor)1,5 m/s²
-
Tool weight with battery (EPTA)1,1 - 1,2 kg
-
Product Dimensions (L x W x H):168 x 66 x 224 mm
Barcode
0088381881883
Symbols:
Portaaton nopeudensäätö
Elektroninen tai mekaanin jarru
Suunnanvaihto
Työvalo
